3D stereo-capable application TerraStereo with the 3D PluraView: compatible and officially certified. (© Schneider Digital)
Over the last 20 years, the capabilities of available LiDAR hardware have developed rapidly and with it the capabilities of processing software, spearheaded by Terrasolid applications. For consistent, precise and digital data workflows in GIS and photogrammetry environments, raw data must first be converted into integrable and thus valuable information components that meet the requirements of the respective applications. The 3D point cloud processing modules from the Finnish provider Terrasolid, such as TerraMatch, TerraScan, TerraModeler and TerraStereo, are highly developed, intelligent and powerful applications that process and model laser points with XYZ coordinates at high speed and display the result in 3D stereo.
The diversity of LiDAR applications has developed just as rapidly in just a few years: surveying and civil engineers use 3D point clouds for terrain modeling, for the construction and monitoring of bridges, dams and high-voltage lines, as well as for determining the quality of road surfaces with millimeter precision and for the high-precision measurement of railroad tracks and the entire railroad infrastructure. Urban planners receive very precise information about the vegetation in cities, while at the same time precise reference points for building measurements are recorded. Archaeologists use precise and RGB-textured LiDAR data to record and reconstruct important cultural monuments. Recently, after the major fire at Notre-Dame, the medieval church in the center of Paris, the remaining structure was completely surveyed using high-resolution LiDAR instruments. These are just a few examples of the use of LiDAR data, which has been processed for many years with the versatile and constantly evolving tools of the Terrasolid applications.
Use cases are evolving due to the increasing diversity and rapid development of LiDAR data acquisition systems. Very small but precise laser scanners are available for “Unmanned Aerial Systems” (UAS), often referred to as “drones”. In larger, single or twin-engine aircraft, very powerful LiDAR instruments are used for higher flight altitudes and for surveying large areas. On the ground (_terrestrial_), LiDAR data acquisition begins with very small scanners that are held in the hand and are therefore ultra-mobile, or – somewhat larger and very precise – laser measuring heads installed on tripods with a range of several hundred meters. These are used in combination with digital cameras, often mounted on vehicle roofs, for fast, mobile LiDAR data acquisition.
Schneider Digital’s stereoscopic 3D PluraView monitors with two screens, which are ‘plug & play’ compatible with Terrasolid’s TerraStereo software, provide a visualization experience of these point clouds in the highest 3D stereo quality. Users benefit from flicker-free, pixel-perfect visualization with a resolution of up to 4K per screen and therefore per eye. The 3D PluraView monitors are the perfect visualization solution for comfortable working with high-resolution LiDAR data in all 3D stereo and VR/AR desktop applications. The compatibility of TerraStereo with the 3D PluraView monitor family has now been officially certified by the manufacturer Schneider Digital.
The LiDAR applications from the Finnish software company Terrasolid are the world’s leading platform when it comes to processing and visualizing point clouds. As a company, Terrasolid has been successfully established in the geodata market for more than 30 years and has been the global market leader specifically with LiDAR software solutions for more than 20 years. Independent of LiDAR data sources and sensors, Terrasolid offers versatile and powerful tools for editing 3D point clouds, feature extraction, terrain visualization and point cloud visualization. With TerraStereo, even very large point clouds with more than 50 billion points can be realistically visualized in 3D stereo at very high speed with freely selectable color textures.
Visualize, analyse, calculate and extract LiDAR data
TerraStereo is specifically tailored for 3D stereo visualization in every Terrasolid workflow and can be combined with all other Terrasolid software products. The workflow with software products from the Terrasolid family usually starts with TerraScan. TerraScan manages, processes and visualizes all types of point clouds. The application offers various import and project structuring tools for very large amounts of data. With this powerful tool, complex buildings, landscapes as well as road and cable networks can be measured, vectorized and precisely modelled in 3D reliably and with high precision. In combination with additional Terrasolid applications such as TerraModeler, TerraMatch, TerraPhoto, TerraSlave and other products, users have all the tools they need for highly automated processing of LiDAR point clouds and the creation of 3D vector data based on them. TerraStereo offers the possibility to visualize buildings, topographies and entire railroad and tramway infrastructures in 3D stereo. The software application is also used to visualize power lines, visualize corridor analyses, display hazardous objects in 3D stereo and allow efficient visual analysis of the condition of road surfaces for risk assessment.
Terrasolid’s software products process LiDAR data from terrestrial and airborne laser scanning systems together with RGB-I image data. Terrasolid is neither limited to specific applications nor to specific laser scanning or camera systems. From calibration, matching and merging of raw data, to the creation of final 3D vector models, orthoimages with TerraPhoto, terrain renderings with and without natural vegetation, the software applications are highly flexible and offer powerful solutions e.g. for surveying and civil engineering, cartography, photogrammetry and surface analysis, but also for archaeology, research and urban development. Terrasolid uses high-performance graphics to convert any point cloud into a clean 3D model or CAD vector elements precisely, quickly and in high quality, saving time and costs and optimizing workflows. The fast data export is a major advantage in smart city and urban planning applications used on desktop, mobile and web platforms, for example.
For the spatial viewing and measurement of 3D models, Terrasolid relies on the detailed and high-contrast 3D stereo display of the passive dual screen systems with beam splitters from Schneider Digital’s 3D PluraView series. These high-end displays are the industry standard for all stereo-capable LiDAR, photogrammetry and GIS applications. The color fidelity of RGB textured point clouds is perfectly enhanced with Schneider Digital’s powerful and innovative 3D stereo monitors. They ensure a razor-sharp display in real time, are completely flicker-free and can be used “plug & play” for all Terrasolid features, such as 3-axis surveying in 3D space.
Present intelligent point clouds impressively and edit them precisely
The up to 28″ 3D PluraView monitors deliver highly detailed, stereoscopic 3D visualizations. Thanks to one monitor per eye, they offer the full resolution of up to 4K with brilliant image brightness. With their optimum ergonomics and passive polarizing filter technology, they ensure fatigue-free working even under normal daylight conditions in the office. Terrasolid users are not the only ones who appreciate the simple handling of the 3D PluraView monitors. This means that 3D models can be easily displayed and measured or edited using a 3D mouse, for example. With the 3D PluraView monitors, Terrasolid users benefit from a sophisticated 3D visualization technology that has been established in the geodata industry for many years.
Schneider Digital is the world’s leading manufacturer and distributor of customized hardware solutions for graphics-intensive computer applications and offers professional users in the fields of GIS and photogrammetry complete workstation solutions for the calculation and visualization of large data sets. The powerful performance of its workstations, in combination with innovative high-end displays, has ensured fast and precise workflows in geodata applications for over 25 years. Even the most complex version of 3D modeling becomes an impressive presentation and high-resolution working model with a 3D PluraView monitor. With the high-end displays from Schneider Digital, professional users of the powerful software suite from Terrasolid get a complete package that has been thought through to the highest level. Measuring, capturing, analyzing and visualizing 3D data with these two innovative technologies is not only convenient, but also a real added value in a demanding GIS workflow. This is why Schneider Digital has now officially certified TerraStereo for 3D stereo visualization with its 3D PluraView monitors.
